Florida Product Approval - FL #239-R29 LMI (Download)
Miami-Dade Approved (HVHZ LMI Rated)
DP= +65/-80 PSF
Sizes up to 53.125” x 83”
Slim structure to maximize glass view and day light opening
Extrusions are 2-3/16” deep to have the minimal impact on interior finish during retrofit
Machine glazed with silicone GE 2000/DS795
Laminated Heat Strengthened Glass with 0.09 thick PVB as interlayer
Silicone glazing gasket and stainless steel screws
Clear, tinted, or reflective glass. Low-e glass for enhanced Solar Heat Gain Coefficient while allowing maximal transparency and visual light transmittance
Powder coat finish. Standard and custom colors. Meeting AAMA 2604 as standard finish (5 years warranty) with possibility to upgrade to AAMA 2605 (10 years warranty)
Aluminum 6063T6 structure
Colonials for design freedom

Specifications
Maximum Size	53.125” x 83”
Maximum Design Pressure	+65/-80 PSF
Glass Thickness / Type	5/16” - Monolithic Annealed Glass (1/8" - .090 - 1/8")
Frame Depth	2 3/16”
Standard Sizes	19 1/8" x 26", 19 1/8" x 38 3/8", 19 1/8" x 50 5/8", 19 1/8" x 59 1/2", 19 1/8" x 63", 19 1/8" x 74 1/4", 19 1/8" x 78", 26 1/2" x 26", 26 1/2" x 38 3/8", 26 1/2"x 50 5/8", 26 1/2" x 59 1/2", 26 1/2" x 63", 26 1/2" x 74 1/4", 26 1/2" x 78", 37" x 26", 37" x 38 3/8", 37" x 50 5/8", 37" x 59 1/2", 37" x 63", 37" x 74 1/4", 37" x 78", 53 1/8" x 26", 53 1/8" x 38 3/8", 53 1/8" x 50 5/8", 53 1/8" x 59 1/2", 53 1/8" x 63", 53 1/8" x 83"
